Anti-corrosive O-ring Pusher Mechanical Seals

Anti-corrosive O-ring pusher Mechanical Seals are a type of sealing device used in various industrial applications to prevent leakage of fluids or gases. These seals are designed to withstand corrosive environments, where the presence of chemicals or other corrosive substances can degrade the sealing performance of standard seals.The main component of an anti-corrosive O-ring pusher mechanical seal is the O-ring, which is made from a material that is resistant to corrosion. This O-ring is placed between two sealing faces, which are pressed together by a pusher mechanism. The pusher mechanism ensures that the seal remains in contact with the sealing faces, providing a tight and secure seal.Anti-corrosive O-ring pusher mechanical seals are commonly used in industries such as chemical processing, oil and gas, pharmaceuticals, and wastewater treatment, where the presence of corrosive substances is common. These seals help to prevent leakage and ensure the safety and efficiency of industrial processes.O Rings And Seals,O Ring Mechanical Seals.

Operational Conditions:

Shaft diameter:16mm to 120mm

Temperature:-20ºC to +200ºC

Pressure:≤0.8MPa

Speed:≤13m/Sec

Materials:

Stationary Ring: Carbon/SiC/TC

Rotary Ring: Carbon/SiC/TC

Secondary Seal: NBR/EPDM/TC

Spring and Metal Parts: SS304/SS316

Application:

Water pumps, sewage pumps, chemical pumps,screw pumps, other rotating equipment,etc.

Packaging:

1.Tissue paper + Carton box

2.As per customer’s requirement
